316 Food Grade 316L Stainless Steel Sheet Coil AB 2B Anti Corrosion Width 5m

Ask Lasest Price
Brand Name :	TISCO
Model Number :	201 304 316L 310S 409L 420 420j1 420j2 430 431 434 436L 439
Certification :	SGS ISO ROHS
Price :	Negotiable
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	2000MT/Month
Delivery Time :	3~15 days

Add to Cart

Product Details
Company Profile

316 Food Grade 316L Stainless Steel Sheet Coil AB 2B Anti Corrosion Width 5m

Description:

Coil set is a phenomenon occurring in industrial sheet metal in which the strip retains a residual curvature as it comes off the coil. The roll forming of two coils exhibiting coil set is studied; each coil has similar tensile and bending properties.

Steel coils are used by various industries, as this type of metal is ideal for building panels, walls, roof panels, power stations, ships, and various other projects and construction undertakings. In addition to different sizes of steel coils, there are also two different primary types: Cold-rolled steel coils.

Stainless Steel Coil Manufacturing Process	Hot Rolled (HR) / Cold Rolled (CR)
Stainless Steel Coil Grades	202 / 304 / 304L / 304H / 309S / 310S / 316 / 316L / 316Ti / 317L / 321 / 321H / 347 / 347H / 904L etc. UNS No. - UNS S30400, UNS S30403, UNS S31008, UNS S31620, UNS S31603, UNS S31603, UNS S31635, UNS S31703, UNS S32100, UNS S34700, UNS S34709, UNS S8904 EN No. - 1.4301, 1.4307, 1.4845, 1.4401, 1.4404, 1.4571, 1.4438, 1.4541, 1.4550, 1.4551, 1.4539
Stainless Steel Coil Thickness	0.6 MM TO 80 MM THICKNESS
Stainless Steel Coil Width	1250 MM / 1500 MM / 2000 MM / 04 Feet / 05 Feet and Custom Cut Width as Per Requirement
Stainless Steel Coil Length	2400 MM / 2420 MM / 6000 MM / 08 Feet / 10 Feet / Coil Cut and Custom Cut Length as Per Requirement
Stainless Steel Coil Surface Finish	2B, 2D, BA, MATT, MATT PVC, No.4, No.5, SB, HR, No.8, Mirror, Hairline, Brush, Textured, Oil base wet Polished, Both sides Polished available.
Stainless Steel Coil Coating	PVC coating Normal / Laser, Film: 100 micrometer, Color: black/white.
Stainless Steel Coil Other Testing	NACE MR0175, Ultrasoung TEST, IGC TEST, Intergranular Corrrosion Test as per ASTM A262 Practice E, Charpy Impact Test, Macro, Grain Size, Hardness, etc.
Stainless Steel Coil Value Added Services	Gas Cutting / CNC Plasma Cutting / Profiling / Rolling / Bending / Sheet Metal Fabrication / Drill / Punch / Machining / Sand Blasting / Shot Blasting / Heat Treatment
Stainless Steel Coil Packaging	Loose / Carrate / Wooden Pallet / Wooden box-a / Plastic Cloth Wraps
Stainless Steel Coil Shipment & Transportation	By Road - Truck / Train Partial Load, Full Load, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes
Stainless Steel Coil Material Test Certificate	Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS, Bureau of Indian Standards BIS Approved ETC

Designation			Chemical composition % by mass max unless stated
UNS No	SAE No	AISI No / Common Name	C	Si	Mn	P	S	Cr	Mo	Ni	Others
S30100	30301	301	0.15	1.00	2.00	0.045	0.030	16.0/18.0	-	6.0/8.0	N 0.10
S30103	-	301L	0.03	1.00	2.00	0.045	0.030	16.0/18.0	-	6.0/8.0	N 0.20
S30153	-	301LN	0.03	1.00	2.00	0.045	0.030	16.0/18.0	-	6.0/8.0	N 0.07/0.20
S30200	30302	302	0.15	0.75	2.00	0.045	0.030	17.0/19.0	-	8.0/10.0	N 0.10
S30215	30302B	302B	0.15	2.00/3.00	2.00	0.045	0.030	17.0/19.0	-	8.0/10.0	-
S30300	30303	303	0.15	1.00	2.00	0.20	0.15 min	17.0/19.0	-	8.0/10.0
S30310	-	XM-5 (303Plus x)	0.15	1.00	2.50/4.50	0.20	0.25 min	17.00/19.00	-	7.00/9.00	-
S30323	30303Se	303Se	0.15	1.00	2.00	0.20	0.060	17.0/19.0	-	8.0/10.0	Se 0.15 min
S30330	-	303Cu	0.15	1.00	2.00	0.15	0.10 min	17.0/19.0	-	6.0/10.0	Cu 2.5/4.0; Se 0.10
S30400	30304	304	0.07	0.75	2.00	0.045	0.030	17.5/19.5	-	8.0/10.5	N 0.10
S30400 A276 for bar	30304	304	0.08	1.00	2.00	0.045	0.030	18.0/20.0		8.0/11.0
S30403	30304L	304L	0.030	0.75	2.00	0.045	0.030	17.5/19.5	-	8.0/12.0	N 0.10
S30403 A276 for bar	30304L	304L	0.030	1.00	2.00	0.045	0.030	18.0/20.0		8.0/12.0
S30430	-	302HQ	0.03	1.00	2.00	0.045	0.030	17.0/19.0	-	8.0/10.0	Cu 3.0/4.0
S30452	-	XM-21 (304HN)	0.08	1.00	2.00	0.045	0.030	18.0/20.0	-	8.00/10.00	N 0.16/0.30
S30453	-	304LN	0.030	0.75	2.00	0.045	0.030	18.0/20.0	-	8.0/12.0	N 0.10/0.16
S30454	-	-	0.03	1.00	2.00	0.045	0.030	18.0/20.0	-	8.0/11.0	N 0.16/0.30
S30500	30305	305	0.12	0.75	2.00	0.045	0.030	17.0/19.0	-	10.5/13.0	-
S30800	30308	308	0.08	1.00	2.00	0.045	0.030	19.0/21.0	-	10.0/12.0	-
S31600	30316	316	0.08	0.75	2.00	0.045	0.030	16.0/18.0	2.00/3.00	10.0/14.0	N 0.10
S31603	30316L	316L	0.030	0.75	2.00	0.045	0.030	16.0/18.0	2.00/3.00	10.0/14.0	N 0.10
S31635	-	316Ti	0.08	0.75	2.00	0.045	0.030	16.0/18.0	2.00/3.00	10.0/14.0	Ti 5x (C+N) / 0.70 N 0.10
S31640	-	316Cb	0.08	0.75	2.00	0.045	0.030	16.0/18.0	2.00/3.00	10.0/14.0	Nb 10x C / 1.10 N 0.10
S31653	-	316LN	0.030	0.75	2.00	0.045	0.030	16.0/18.0	2.00/3.00	10.0/14.0	N 0.10/0.16
S31700	30317	317	0.08	0.75	2.00	0.045	0.030	18.0/20.0	3.0/4.0	11.0/15.0	N 0.10
S31703	-	317L	0.030	0.75	2.00	0.045	0.030	18.0/20.0	3.00/4.00	11.0/15.0	N 0.10
S31725	-	317LM	0.030	0.75	2.00	0.045	0.030	18.0/20.0	4.0/5.0	13.5/17.5	N 0.20
S31726	-	317LMN	0.030	0.75	2.00	0.045	0.030	17.0/20.0	4.0/5.0	13.5/17.5	N 0.10/0.20
S31753	-	317LN	0.030	0.75	2.00	0.045	0.030	18.0/20.0	3.0/4.0	11.0/15.0	N 0.10/0.22
S32100	30321	321	0.08	0.75	2.00	0.045	0.030	17.0/19.0	-	9.0/12.0	Ti 5 x C min/0.70 N 0.10
S34700	30347	347	0.08	0.75	2.00	0.045	0.030	17.0/19.0	-	9.0/13.0	Nb+Ta 10 x C min/1.0
S34720	-	347F	0.08	1.00	2.00	0.040	0.18/0.35	17.00/19.00	0.75	9.00/12.00	Nb 10xC / 1.10; Cu 0.75; Ta 0.05
S34723	-	347FSe	0.08	1.00	2.00	0.11/0.17	0.030	17.00/19.00	0.75	9.00/12.00	Nb 10xC / 1.10; Cu 0.75; Se 0.15/0.35; Ta 0.05
S34800	30348	348	0.08	0.75	2.00	0.045	0.030	17.0/19.0	-	9.00/13.0	Nb+Ta 10 x C / 1.00; Ta:0.10 max; Co 0.20
S38400	30384	384	0.04	1.00	2.00	0.045	0.030	15.0/17.0	-	17.0/19.0	-

Product Details:

Shipping:

Quality inspection:

Application

About us:

workshop:

service:

certificate:

FAQ:

Q: Does the factory have the goods in stock?

A: You can leave your e-mail and our sales will contact you. You can consult our sales. If you have any special requirements on the products. We can customize for you.

Q: What are your main products for sale?

A: mainly provides 1-8 series stainless steel /aluminium foil, coil, plate and high magnesium aluminum alloy.

All of them can be customized according to customers’ requirements. Welcome to send inquiry to us.
