    304 316 10mm 3mm Thick Plate Stainless Steel Cut Punch Sheet 2B 8K Stainless Steel

    Ask Lasest Price
    Brand Name : TISCO
    Model Number : 202 304 316 201 310S 904L
    Certification : SGS ISO ROHS
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 2000MT/Month
    Delivery Time : 3~15 days
    • Product Details
    • Company Profile

    304 316 10mm 3mm Thick Plate Stainless Steel Cut Punch Sheet 2B 8K Stainless Steel

    Grade 304 Chequered is the standard "18/8" stainless; it is the most versatile and most widely used Chequered, available in a wider range of products, forms and finishes than any other. It has excellent forming and welding characteristics.


    The balanced austenitic structure of Grade 304 enables it to be severely deep drawn without intermediate annealing, which has made this grade dominant in the manufacture of drawn stainless parts such as sinks, hollow-ware and saucepans. For these applications it is common to use special "304DDQ" (Deep Drawing Quality) variants.


    Grade 304 Chequered Plate is readily brake or roll formed into a variety of components for applications in the industrial, architectural, and transportation fields. Grade 304 also has outstanding welding characteristics. Post-weld annealing is not required when welding thin sections


    Plate cutting is done either by mechanical means or by thermal processes. In mechanical process, cutting is done by applying a shearing force either using guillotine shear or high pressure water jet.



    Chemical element composition:


    Grade
    C
    Si
    Mn
    P
    S
    Ni
    Cr
    Mo
    201
    ≤0 .15
    ≤0 .75
    5. 5-7. 5
    ≤0.06
    ≤ 0.03
    3.5 -5.5
    16 .0 -18.0
    –
    202
    ≤0 .15
    ≤l.0
    7.5-10.0
    ≤0.06
    ≤ 0.03
    4.0-6.0
    17.0-19.0
    –
    301
    ≤0 .15
    ≤l.0
    ≤2.0
    ≤0.045
    ≤ 0.03
    6.0-8.0
    16.0-18.0
    –
    302
    ≤0 .15
    ≤1.0
    ≤2.0
    ≤0.035
    ≤ 0.03
    8.0-10.0
    17.0-19.0
    –
    304
    ≤0 .0.08
    ≤1.0
    ≤2.0
    ≤0.045
    ≤ 0.03
    8.0-10.5
    18.0-20.0
    –
    304L
    ≤0.03
    ≤1.0
    ≤2.0
    ≤0.035
    ≤ 0.03
    9.0-13.0
    18.0-20.0
    –
    309S
    ≤0.08
    ≤1.0
    ≤2.0
    ≤0.045
    ≤ 0.03
    12.0-15.0
    22.0-24.0
    –
    310S
    ≤0.08
    ≤1.5
    ≤2.0
    ≤0.035
    ≤ 0.03
    19.0-22.0
    24.0-26.0
    316
    ≤0.08
    ≤1.0
    ≤2.0
    ≤0.045
    ≤ 0.03
    10.0-14.0
    16.0-18.0
    2.0-
    3.0
    316L
    ≤0 .03
    ≤1.0
    ≤2.0
    ≤0.045
    ≤ 0.03
    12.0 – 15.0
    16 .0 -1 8.0
    2.0 –
    3.0
    321
    ≤ 0 .08
    ≤1.0
    ≤2.0
    ≤0.035
    ≤ 0.03
    9.0 – 13 .0
    17.0 -1 9.0
    –
    630
    ≤ 0 .07
    ≤1.0
    ≤1.0
    ≤0.035
    ≤ 0.03
    3.0-5.0
    15.5-17.5
    –
    631
    ≤0.09
    ≤1.0
    ≤1.0
    ≤0.030
    ≤0.035
    6.50-7.75
    16.0-18.0
    –
    904L
    ≤ 2 .0
    ≤0.045
    ≤1.0
    ≤0.035
    –
    23.0·28.0
    19.0-23.0
    4.0-5.0
    2205
    ≤0.03
    ≤1.0
    ≤2.0
    ≤0.030
    ≤0.02
    4.5-6.5
    22.0-23.0
    3.0-3.5
    2507
    ≤0.03
    ≤0.8
    ≤1.2
    ≤0.035
    ≤0.02
    6.0-8.0
    24.0-26.0
    3.0-5.0
    2520
    ≤0.08
    ≤1.5
    ≤2.0
    ≤0.045
    ≤ 0.03
    0.19 -0. 22
    0. 24 -0 . 26
    –
    410
    ≤0.15
    ≤1.0
    ≤1.0
    ≤0.035
    ≤ 0.03
    –
    11.5-13.5
    –
    430
    ≤0.1 2
    ≤0.75
    ≤1.0
    ≤ 0.040
    ≤ 0.03
    ≤0.60
    16.0 -18.0
    Workshop:

    Processing:



    Related product:




    FAQ:
    Q1: Can you do OEM for me?
    A1:We accept all OEM orders,just contact us and give me your design.we will offer you a reasonable price and make samples for you ASAP.
    Q2:Can you send products to my country?
    A2: Sure, we can. If you do not have your own ship forwarder, we can help you.
